KE-668LK Automatic Aluminum Wood Integrated Edge Sealing Machine

5 0 Reviews

Price: $ 26100 / SET

Model:
KE-688LK
Brand:
KIHON

Availability:

Quantity:



Buy Now Add to Cart

Features

Pre-milling

The pre-milling cutter grinds and trims the edge of the board, which can make the edge of the board smooth and burr free. It can make the side band and the board more closely bonded.

Glue pot 1

The glue pot is heated quickly, the glue is uniformly covered in the rolling bearing, and the glue can be uniformly obtained when the plate passes through to effectively glue the side strip, so that it is glued without gap.

Pressing

Multi-point contact and tight paste, make the sealing tape and the panel more strongly fit.

No-clean PUR

Standard PUR single color glue pot without cleaning, to reduce cleaning glue pot, waste glue and other problems. The adhesive contact surface of the aluminum plate is small, while the PUR glue is strong.

Track pressing

Crawler-type pressing is more accurate, does not hurt the plate, the glue line is thinner, and the edge is more beautiful.

End cutting

The single guide rail is designed to 45°, which can more accurately cut the excess side tape after the edge sealing of the board. At the same time, the dust suction port is added above the board, which can suction out the removed side waste to prevent residual damage to the parts in the machine.

Trimming

The side tape on both sides of the panel is cut so that the tape is parallel to the height of the panel and the edge effect is more beautiful.

Corner rounding

The edge of the four corners of the panel is chamfered to make the edge of the four corners more delicate, smooth and rounded.

Flat scraping

On the top and bottom of the edge sealing belt after trimming, scrape out the α Angle circular edge, make the edge sealing effect is more exquisite.

Horizontal scraping

The upper and lower scraping are independently controlled, the position and direction of the upper and lower scraping board can be manually adjusted, and the board is fed by the slide block, which can effectively avoid the beating of the scraping edge.

Cleaning

Clean the dirt on the top and bottom sides of the panel after the edge sealing, make the panel can reduce the subsequent cleaning process.

Buffing

After the edge sealing is completed, the panel needs to be polished to remove the residual glue and smooth the surface to make the board look smoother and more beautiful.

Description

Automatic Aluminum Wood Integrated Edge Sealing Machine KE-668LK

KE-668LK automatic aluminum wood integrated edge sealing machine, the highest speed up to 26m/min. This model has complete functions, stable and powerful system, intelligent operation control and high-speed and efficient production, one device can adapt to the edge sealing of aluminum honeycomb board and wood, track pressing, double rail end cutting, double knife tracking, double horizontal scraping, so that the edge sealing effect is better.

Technical Parameter

Model:	KE-668LK
Total power	31kw
Overall size	980011001750mm
Feeding speed	18-26m/min
Tape thickness	0.4-3mm
Panel thickness	9-60mm
Panel length	120mm
Panel width	≥80mm
Working pressure	0.7Mpa
Suction opening	Φ100

Solution Technology

Main functions: Separating agent → Pre-milling → Sol R1 → Cluing R1 → Sol R2 → Pressing → Split double rails end cutting → Rough trimming → Fine trimming → Double trace trimming → Scraping 1→ Scraping 2→ Buffing 1→ Buffing 2.

Applicable Industry

Edge banding machines are mainly used for banding the edges of various panel furniture. For instance, cabinets, wardrobes, shelves, custom furniture, office furniture, tables, chairs, windows, doors, cupboards, and other wood products.

Our Advantages

1. The welded steel plate body is firm and stable to ensure that each process group can work accurately.

2. A device can adapt to aluminum honeycomb panel edge banding.

3.There are two kinds of pressing methods, including six wheel pressing and crawler pressing, which can make the edge band tape and the panel fit more closely, and the edge banding effect is better.

4. Strict and careful assembly process, each machine must go through strict testing and deployment before packaging.

Application

Applicable

Full-automatic edge banding machine is suitable for the edge sealing processing of medium density fiberboard, joinery board, solid wood board, particle board, polymer door board, plywood and other boards.

FAQ

FAQ

1.How to deal with the exceeded glue during the banding process?

Our automatic edge banding machines have rough trimming, fine trimming, and polishing functions. All these functions help to trim and polish the edges to remove the exceeded glue.
2.Why the edge cannot be banded sometimes?

Please check if the room temperature is below 8℃， or if the banding speed is too slow when the edge cannot be banded.
